ACS770KCB-150U-PFF-T - Allegro MicroSystems
Open Loop Current Sensor AC/DC Current 5V Automotive 5-Pin Case CB-PFF Tube
Technical Details
| Accuracy | 0.5% |
| Ambient Temperature Range High | 125°C |
| Bandwidth | 120kHz |
| Case/Package | 125 |
| China RoHS | Compliant |
| Current Rating | 15mA |
| Current Sensing | 150A |
| Frequency | 120kHz |
| Height | 7mm |
| Length | 13mm |
| Lifecycle Status | Production |
| Linearity | 1% |
| Max Junction Temperature (Tj) | 165°C |
| Max Operating Temperature | 125°C |
| Max Supply Current | 15mA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Through Hole |
| Number of Channels | 1 |
| Number of Pins | 5 |
| Number of Terminals | 5 |
| Operating Supply Current | 10mA |
| Polarity | Unidirectional |
| Quiescent Current | 10mA |
| REACH SVHC | Yes |
| Response Time | 4.6µs |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Sensing Method | Hall Effect |
| Sensitivity (mV/A) | 26.7mV/A |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
