ACS772ECB-400B-PFF-T - Allegro MicroSystems
ACS772 Series 5 V ±400 A 1-Channel SMT Hall Effect Current Sensor IC - CB-5-PFF
Technical Details
| Accuracy | 0.9% |
| Ambient Temperature Range High | 85°C |
| China RoHS | Compliant |
| Height | 7mm |
| Introduction Date | 2019-01-30 |
| Length | 13mm |
| Lifecycle Status | Production |
| Max Junction Temperature (Tj) | 165°C |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Number of Terminals | 5 |
| Operating Supply Current | 10mA |
| Output Configuration | Analog |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sensing Method | Hall Effect |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
