ACS773ECB-200B-PFF-T - Allegro MicroSystems
Open Loop Current Sensor AC/DC Current 3.3V Automotive 5-Pin Case CB-PFF Tube
Technical Details
| Accuracy | 1% |
| Ambient Temperature Range High | 85°C |
| Bandwidth | 200kHz |
| China RoHS | Compliant |
| Height | 7mm |
| Introduction Date | 2018-02-23 |
| Isolation Voltage | 4800Vrms |
| Length | 13mm |
| Lifecycle Status | Production |
| Max Junction Temperature (Tj) | 165°C |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.6V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Nominal Supply Voltage (DC) | 3V |
| Number of Terminals | 5 |
| Operating Supply Current | 10mA |
| Output Configuration | Analog |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sensing Method | Hall Effect |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
