ADXL363BCCZ-RL7 - Analog Devices
Accelerometer and Temperature Digital Output 2V 16-Pin LGA T/R
Technical Details
| Axis | X, Y, Z |
| Bandwidth | 400Hz |
| Case/Package | LGA |
| Height | 1.14mm |
| Interface | SPI |
| Lead Free | Contains Lead |
| Length | 3.3mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PRODUCTION |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.5V |
| Max Supply Voltage (DC) | 3.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.6V |
| Min Supply Voltage (DC) | 1.6V |
| Mount | Surface Mount |
| Number of Pins | 16 |
| Operating Supply Current | 1.95µA |
| Output Type | Digital |
| REACH SVHC | No |
| Resolution | 1.5B |
| RoHS | Compliant |
| Schedule B | 9031808080, 9031808080|9031808080|9031808080|9031808080|9031808080 |
| Sensor Type | 3 Axis |
| Width | 3.1mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
