PVT322SPBF - Infineon
PVT Photovoltaic 250 V 0.17 A 10 Ohm DPST (2 Form A) Solid State Relay - DIP-8
Technical Details
| Ambient Temperature Range High | 85°C |
| Approvals | UL |
| Capacitance | 50pF |
| Case/Package | SMD/SMT |
| China RoHS | Compliant |
| Data Polarity | DC |
| Depth | 6.47mm |
| Forward Current | 25mA |
| Height | 3.42mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.95.00 |
| Input Current | 2mA |
| Introduction Date | 1996-10-01 |
| Isolation Voltage | 4000Vrms |
| Lead Free | Contains Lead |
| Length | 9.39mm |
| Lifecycle Status | Production |
| Load Current | 170mA |
| Max Input Current | 25mA |
| Max Length | 9.4mm |
| Max Operating Temperature | 85°C |
| Max Output Voltage | 250V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Contacts | 1 |
| Number of Elements | 2 |
| Number of Pins | 8 |
| On-State Resistance | 10Ω |
| Output Current | 170mA |
| Output Voltage | 250V |
| Package Quantity | 2000 |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | Relay |
| Resistance | 10Ω |
| RoHS | Compliant |
| Schedule B | 8541408000|8541408000|8541408000|8541408000|8541408000 |
| Termination | Gull Wing |
| Throw Configuration | DP, DPST |
| Turn-On Delay Time | 3ms |
| Width | 6.47mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
