MLX90614ESF-DCH-000-TU - Melexis
MLX90614 Series 3.6 V 25 mA Single and Dual Zone Infra Red Thermometer - TO-39
Technical Details
| Ambient Temperature Range High | 85°C |
| Body Material | Metal |
| Case/Package | TO-39 |
| Height | 8.88mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.01 |
| Interface | SMBus |
| Introduction Date | 2012-08-29 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Max Output Current | 25mA |
| Max Supply Voltage | 3.6V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.6V |
| Number of Circuits | 1 |
| Number of Terminals | 4 |
| Operating Supply Voltage | 3V |
| Output Type | PWM |
| REACH SVHC | Yes |
| Resolution | 2B |
| RoHS | Compliant |
| Sensing Method | Infrared (IR) |
| Temperature Grade | Industrial |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
