Technical Details
| Projected EOL Date | 2034-12-09 |
| Accuracy | 4% |
| Case/Package | SOT-23 |
| Country of Assembly | Thailand |
| Country of Fabrication | Taiwan |
| Country of Origin | Thailand |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1.2954mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Introduction Date | 2003-12-09 |
| Lead Free | Lead Free |
| Length | 3.0988mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Operating Temperature | 135°C |
| Max Output Current | 20mA |
| Max Supply Voltage | 5.5V |
| Max Supply Voltage (DC) | 5.5V |
| Min Operating Temperature | -55°C |
| Min Supply Voltage | 2.7V |
| Min Supply Voltage (DC) | 2.7V |
| Mount | Surface Mount |
| Number of Pins | 5 |
| Operating Supply Current | 17µA |
| Output Current | 20mA |
| Output Type | ANALOG, Digital |
| Output Voltage | 2.16V |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Sensor Type | Temperature |
| Switching Temperature | 120°C |
| Termination | SMD/SMT |
| Width | 2.9972mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
TME
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Microchip | Unknown | ||
| Microchip | Unknown | ||
| Microchip | Production | ||
| Analog Devices | Unknown | ||
| Microchip | Unknown | ||
| Microchip | Production | ||
| onsemi | Obsolete | ||
| Analog Devices | Unknown | ||
| Analog Devices | Production | ||
| Microchip | Production |
