TC74A1-5.0VAT - Microchip
SENSOR DIGITAL -40C-125C TO220-5 "Temperature Sensor Digital, Local -40°C ~ 125°C 7 b TO-220-5"
Technical Details
| Projected EOL Date | 2034-01-01 |
| Country of Assembly | China |
| Country of Fabrication | United States of America |
| Country of Origin | China |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 15.57mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Interface | 2-Wire, I2C, SMBus, Serial |
| Introduction Date | 2002-01-01 |
| Lead Free | Lead Free |
| Length | 10.54mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 5.5V |
| Max Supply Voltage (DC) | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.7V |
| Min Supply Voltage (DC) | 2.7V |
| Mount | Through Hole |
| Number of Bits | 8 |
| Number of Pins | 5 |
| Operating Supply Current | 350µA |
| Output Current | 50mA |
| Output Type | Digital, I2C |
| Packaging | Bulk |
| Radiation Hardening | No |
| Resolution | 1B |
| RoHS | Compliant |
| Width | 4.7mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
