G2R-1-SN DC24(S) - Omron
Relay; E-mech; Power; SPDT; Cur-rtg 10A; Ctrl-v 24DC; Vol-rtg 250/30AC/DC; Socket Mnt
Technical Details
| Ambient Temperature Range High | 70°C |
| Approvals | CE, CSA, UL, VDE |
| Coil Current | 22mA |
| Coil Power | 530mW |
| Coil Resistance | 1.113kΩ |
| Coil Type | Non-Latching |
| Coil Voltage (AC) | 24V |
| Coil Voltage (DC) | 16.8V |
| Contact Current Rating | 10A |
| Contact Material | Silver |
| Contact Voltage Rating (AC) | 440V |
| Country of Origin | Indonesia |
| Current Rating | 10A |
| Depth | 13mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 100kcycles |
| Height | 35.5mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.49.00.50 |
| Insulation Resistance | 1GΩ |
| Introduction Date | 2005-03-16 |
| Lead Free | Lead Free |
| Length | 29mm |
| Lifecycle Status | Production |
| Max Current Rating | 10A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (AC) | 440V |
| Max Voltage Rating (DC) | 125V |
| Min Operating Temperature | -40°C |
| Mount | Socket, Socketable |
| Number of Contacts | 1 |
| Number of Pins | 5 |
| Operate Time | 15ms |
| Packaging | Bulk |
| Power Consumption | 90W |
| Ratings | IP40 |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 5ms |
| Response Time | 15ms |
| RoHS | Compliant |
| Switching Capacity | 2.5kW |
| Switching Current | 10A |
| Termination | Quick Connect, Solder |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 440V |
| Voltage Rating (DC) | 24V |
| Width | 13mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
