G2R-2A4-DC12 - Omron
Power Relay, Dpst-No, 12Vdc, 4A, Tht Rohs Compliant: Yes |Omron G2R-2A4 DC12
Technical Details
| Ambient Temperature Range High | 70°C |
| Case/Package | DIP |
| Coil Current | 44mA |
| Coil Power | 530mW |
| Coil Resistance | 275Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 8.4V |
| Contact Current Rating | 5A |
| Contact Material | Silver |
| Contact Resistance | 50mΩ |
| Contact Voltage Rating (AC) | 250V |
| Country of Origin | Indonesia |
| Current Rating | 4A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 100kcycles |
| Height | 25.5mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.20 |
| Insulation Resistance | 1GΩ |
| Introduction Date | 2007-02-14 |
| Lead Free | Lead Free |
| Length | 29mm |
| Lifecycle Status | Production |
| Max Current Rating | 5A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (AC) | 380V |
| Max Voltage Rating (DC) | 30V |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 2 |
| Number of Pins | 6 |
| Number of Terminals | 6 |
| Operate Time | 15ms |
| Power Consumption | 530mW |
| Power Rating | 530mW |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 5ms |
| Response Time | 15ms |
| RoHS | Compliant |
| Switching Current | 4A |
| Termination | PC Pin |
| Throw Configuration | DPST |
| Weight | 17g |
| Width | 13mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
