G2RL-1A-E-CF-DC24 - Omron
Electromechanical Relay 24VDC 1.44KOhm 16A SPST-NO (29x12.7x15.7)mm THT Power Relay
Technical Details
| Ambient Temperature Range High | 85°C |
| Case/Package | DIP |
| Coil Current | 17mA |
| Coil Power | 400mW |
| Coil Resistance | 1.44kΩ |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 16.8V |
| Contact Current Rating | 16A |
| Contact Material | Cadmium, Silver |
| Contact Resistance | 100mΩ |
| Contact Voltage Rating (AC) | 440V |
| Current Rating | 16A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 150kcycles |
| Height | 15.7mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.49.00.75 |
| Introduction Date | 2003-05-01 |
| Lead Free | Lead Free |
| Length | 29mm |
| Lifecycle Status | Production |
| Max Current Rating | 16A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 440V |
| Max Voltage Rating (DC) | 300V |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 6 |
| Operate Time | 15ms |
| Power Consumption | 53mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 2ms |
| Response Time | 7ms |
| RoHS | Compliant |
| Switching Current | 16A |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Weight | 12g |
| Width | 12.7mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
