G2RL-1A4-E-CF-DC12 - Omron
Silver Alloy() 12V 16A Normal Open: 1A(SPST-Normal Open) DIP, 12.5x28.8mm Power Relays ROHS
Technical Details
| Ambient Temperature Range High | 85°C |
| Coil Current | 33mA |
| Coil Power | 400mW |
| Coil Resistance | 360Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 8.4V |
| Contact Current Rating | 16A |
| Contact Material | Cadmium, Silver |
| Contact Resistance | 100mΩ |
| Contact Voltage Rating (AC) | 440V |
| Current Rating | 12A |
| Height | 15.7mm |
| Lead Free | Lead Free |
| Length | 29mm |
| Lifecycle Status | Production |
| Max Current Rating | 16A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 440V |
| Max Voltage Rating (DC) | 300V |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 1 |
| Operate Time | 15ms |
| Power Consumption | 33mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 2ms |
| Response Time | 7ms |
| RoHS | Compliant |
| Switching Current | 12A |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Width | 12.7mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
