G2RL-24-DC12 - Omron
Power PCB Relay, G2RL8119E ; G2RL-24 DC12 BY OMB | Omron Automation G2RL-24 DC12 BY OMB
Technical Details
| Ambient Temperature Range High | 85°C |
| Approvals | CSA, UL, VDE |
| Case/Package | DIP |
| Coil Current | 33mA |
| Coil Power | 400mW |
| Coil Resistance | 360Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 8.4V |
| Contact Current Rating | 8A |
| Contact Material | Cadmium, Silver |
| Contact Voltage Rating (AC) | 440V |
| Current Rating | 8A |
| Depth | 12.7mm |
| Height | 15.7mm |
| Lead Free | Lead Free |
| Length | 29mm |
| Lifecycle Status | Production |
| Max Current Rating | 8A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 440V |
| Max Voltage Rating (DC) | 300V |
| Min Operating Temperature | -40°C |
| Mount | PCB, Through Hole |
| Number of Contacts | 2 |
| Number of Pins | 8 |
| Operate Time | 15ms |
| Power Consumption | 400mW |
| Power Rating | 400mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 5ms |
| Response Time | 15ms |
| RoHS | Compliant |
| Schedule B | 8536490050, 8536490050|8536490050|8536490050|8536490050|8536490050 |
| Switching Current | 8A |
| Termination | PC Pin |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 440V |
| Voltage Rating (DC) | 300V |
| Weight | 12g |
| Width | 12.7mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
