Technical Details
| Ambient Temperature Range High | 85°C |
| Capacitance | 800fF |
| Data Polarity | DC |
| Forward Current | 20mA |
| Height | 1.3mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.95.00 |
| Input Current | 5mA |
| Introduction Date | 2015-02-19 |
| Isolation Voltage | 500Vrms |
| Lifecycle Status | Production |
| Load Current | 200mA |
| Max Junction Temperature (Tj) | 125°C |
| Max Length | 2.45mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -20°C |
| Mount | Surface Mount |
| Number of Contacts | 1 |
| Number of Elements | 1 |
| On-State Resistance | 5Ω |
| Output Current | 200mA |
| Output Voltage | 16V |
| REACH SVHC | Yes |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
