Technical Details
| Ambient Temperature Range High | 85°C |
| Capacitance | 800fF |
| Case/Package | DIP |
| Data Polarity | DC |
| Forward Current | 25mA |
| Height | 3.65mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.95.00 |
| Input Current | 5mA |
| Introduction Date | 2016-04-27 |
| Isolation Voltage | 2500Vrms |
| Lifecycle Status | Production |
| Load Current | 5A |
| Max Junction Temperature (Tj) | 125°C |
| Max Length | 9.66mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | PCB |
| Number of Contacts | 1 |
| Number of Elements | 1 |
| Number of Terminals | 8 |
| On-State Resistance | 50mΩ |
| Output Current | 5A |
| Output Voltage | 48V |
| REACH SVHC | Yes |
| Relay Type | Relay |
| Resistance | 22mΩ |
| RoHS | Compliant |
| Termination | PC Pin |
| Throw Configuration | SPST |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
