G5LE-1 DC48 - Omron
G5LE Cubic PCB Power Relay Flux Protection SPDT 10A 46VDC Through Hole Tray
Technical Details
| Ambient Temperature Range High | 85°C |
| Coil Current | 8mA |
| Coil Power | 400mW |
| Coil Resistance | 5.76kΩ |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 36V |
| Contact Current Rating | 10A |
| Contact Material | Silver, Tin |
| Contact Voltage Rating (AC) | 250V |
| Country of Origin | Malaysia |
| Current Rating | 10A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 36kcycles |
| Height | 19mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.20 |
| Introduction Date | 2003-05-27 |
| Lead Free | Lead Free |
| Length | 22.5mm |
| Lifecycle Status | Production |
| Max Current Rating | 8A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 30V |
| Min Operating Temperature | -25°C |
| Mount | Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 5 |
| Operate Time | 10ms |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 12.2ms |
| Response Time | 10.6ms |
| RoHS | Compliant |
| Switching Current | 10A |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| Weight | 12g |
| Width | 15.6mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
