Technical Details
| Ambient Temperature Range High | 85°C |
| Coil Current | 150mA |
| Coil Power | 750mW |
| Coil Resistance | 33.3Ω |
| Coil Type | Latching, Dual Coil |
| Coil Voltage (DC) | 3.5V |
| Contact Current Rating | 16A |
| Contact Material | Silver |
| Contact Resistance | 100mΩ |
| Contact Voltage Rating (AC) | 250V |
| Current Rating | 16A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 50kcycles |
| Height | 15.7mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.50 |
| Insulation Resistance | 1GΩ |
| Introduction Date | 2014-03-26 |
| Length | 29mm |
| Lifecycle Status | Production |
| Max Current Rating | 16A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 24V |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 1 |
| Number of Terminals | 9 |
| Operate Time | 15ms |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 10ms |
| Response Time | 10ms |
| RoHS | Compliant |
| Switching Current | 16A |
| Termination | PC Pin |
| Throw Configuration | SPDT |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
