Technical Details
| Ambient Temperature Range High | 70°C |
| Approvals | CSA, UL |
| Case/Package | DIP |
| Coil Current | 30mA |
| Coil Power | 360mW |
| Coil Resistance | 400Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 9V |
| Contact Current Rating | 600mA |
| Contact Material | Silver |
| Contact Voltage Rating (AC) | 125V |
| Current Rating | 2A |
| Depth | 10.1mm |
| Height | 11.5mm |
| Lead Free | Lead Free |
| Length | 20.5mm |
| Lifecycle Status | Production |
| Max Current Rating | 2A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (AC) | 125V |
| Max Voltage Rating (DC) | 30V |
| Min Operating Temperature | -25°C |
| Mount | PCB, Through Hole |
| Number of Contacts | 2 |
| Number of Pins | 8 |
| Operate Time | 7ms |
| Power Rating | 360mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 6.5ms |
| Response Time | 7.5ms |
| RoHS | Compliant |
| Switching Current | 1A |
| Termination | PC Pin |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 125V |
| Voltage Rating (DC) | 125V |
| Weight | 6g |
| Width | 10.1mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
