G6C-2114P-US-DC5 - Omron
Electromechanical Relay 5VDC 125Ohm 8A SPST-NO/SPST-NC (20x15x10)mm THT Power Relay
Technical Details
| Ambient Temperature Range High | 70°C |
| Approvals | CSA, UL, VDE |
| Coil Current | 40mA |
| Coil Power | 200mW |
| Coil Resistance | 125Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 3.5V |
| Contact Current Rating | 8A |
| Contact Material | Cadmium, Silver |
| Contact Resistance | 30mΩ |
| Contact Voltage Rating (AC) | 380V |
| Current Rating | 8A |
| Depth | 15mm |
| Electrical Life | 100kcycles |
| Height | 10mm |
| Insulation Resistance | 100MΩ |
| Lead Free | Lead Free |
| Length | 20mm |
| Lifecycle Status | Production |
| Max Current Rating | 8A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (AC) | 380V |
| Max Voltage Rating (DC) | 125V |
| Min Operating Temperature | -25°C |
| Mount | PCB, Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 6 |
| Number of Terminals | 4 |
| Operate Time | 10ms |
| Power Consumption | 200mW |
| Power Rating | 200mW |
| Radiation Hardening | No |
| Relay Type | General Purpose |
| Release Time | 10ms |
| Response Time | 10ms |
| RoHS | Compliant |
| Sealable | SEALED TYPE |
| Switching Current | 8A |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 380V |
| Voltage Rating (DC) | 125V |
| Weight | 5.6g |
| Width | 15mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
