G6E-134PL-ST-US-DC12 - Omron
Power/Signal Relay, Spdt, Momentary, 0.033A (Coil), 12Vdc (Coil), 400Mw (Coil), 3A (Contact),
Technical Details
| Ambient Temperature Range High | 70°C |
| Approvals | CSA, UL |
| Coil Current | 33mA |
| Coil Power | 400mW |
| Coil Resistance | 360Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 8.4V |
| Contact Current Rating | 3A |
| Contact Material | Silver |
| Contact Resistance | 50mΩ |
| Contact Voltage Rating (AC) | 250V |
| Current Rating | 3A |
| Depth | 9.91mm |
| Height | 8.38mm |
| Lead Free | Lead Free |
| Length | 16mm |
| Lifecycle Status | Production |
| Max Current Rating | 3A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 220V |
| Min Operating Temperature | -40°C |
| Mount | PCB, Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 5 |
| Operate Time | 5ms |
| Power Consumption | 400mW |
| Radiation Hardening | No |
| REACH SVHC | Unknown |
| Relay Type | General Purpose |
| Release Time | 8ms |
| Response Time | 8ms |
| RoHS | Compliant |
| Switching Current | 3A |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 250V |
| Weight | 2.7g |
| Width | 10mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Unknown
