Technical Details
| Ambient Temperature Range High | 85°C |
| Coil Current | 44mA |
| Coil Power | 220mW |
| Coil Resistance | 113Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 3.5V |
| Contact Current Rating | 8A |
| Contact Material | Silver |
| Contact Resistance | 100mΩ |
| Contact Voltage Rating (AC) | 250V |
| Current Rating | 10A |
| Depth | 10mm |
| Electrical Life | 50kcycles |
| Height | 12.3mm |
| Insulation Resistance | 1GΩ |
| Length | 28.5mm |
| Lifecycle Status | Production |
| Max Current Rating | 5A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 400V |
| Max Voltage Rating (DC) | 30V |
| Min Operating Temperature | -40°C |
| Mount | PCB, Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 5 |
| Number of Terminals | 5 |
| Operate Time | 10ms |
| Radiation Hardening | No |
| Relay Type | General Purpose |
| Release Time | 5ms |
| Response Time | 10ms |
| RoHS | Compliant |
| Switching Current | 10A |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 400V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
