Technical Details
| Ambient Temperature Range High | 55°C |
| Approvals | CSA, UL, VDE |
| Coil Current | 37mA |
| Coil Power | 900mW |
| Coil Resistance | 650Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 19.2V |
| Contact Current Rating | 10A |
| Contact Material | Silver |
| Contact Voltage Rating (AC) | 110V |
| Country of Origin | Indonesia |
| Current Rating | 10A |
| Depth | 22.5mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 500kcycles |
| Height | 35.56mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.20 |
| Introduction Date | 2005-03-16 |
| Lead Free | Lead Free |
| Length | 43.94mm |
| Lifecycle Status | Production |
| Max Current Rating | 10A |
| Max Operating Temperature | 55°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 24V |
| Min Operating Temperature | -25°C |
| Mount | Chassis Mount, Flanges, Socket, Surface Mount |
| Number of Contacts | 2 |
| Number of Pins | 8 |
| Operate Time | 25ms |
| Packaging | Bulk |
| Power Consumption | 900mW |
| Radiation Hardening | No |
| REACH SVHC | Unknown |
| Relay Type | General Purpose |
| Release Time | 25ms |
| Response Time | 25ms |
| RoHS | Non-Compliant |
| Schedule B | 8536490075|8536490075|8536490075|8536490075|8536490075 |
| Termination | Quick Connect |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 250V |
| Voltage Rating (DC) | 125V |
| Width | 22.6mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Unknown
