Technical Details
| Coil Current | 40mA |
| Coil Power | 200mW |
| Coil Resistance | 125Ω |
| Coil Voltage (DC) | 4V |
| Contact Current Rating | 16A |
| Contact Resistance | 100mΩ |
| Contact Voltage Rating (AC) | 277V |
| Current Rating | 16A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 50kcycles |
| Height | 18.8mm |
| Insulation Resistance | 1GΩ |
| Introduction Date | 2013-11-20 |
| Length | 24mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 1 |
| Number of Terminals | 4 |
| Release Time | 15ms |
| Response Time | 15ms |
| RoHS | Compliant |
| Schedule B | 8536490075, 8536490075|8536490075|8536490075|8536490075|8536490075 |
| Switching Current | 16A |
| Throw Configuration | SPST |
Compliance
RoHS : Unconfirmed
Images
Onlinecomponents.com
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production |
Authorized Distributors
Non-Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Bettlink |
HK: 273
|
$ | 5.0652 | 4.4432 | 4.4432 | 4.0392 | 3.5613 | 3.3597 | ||
| Ansinor |
CN: 263
|
$ | 5.3645 | 5.3645 | 4.1487 | 3.7556 | 3.7556 | |||
