ADW1203HTW - Panasonic
DW Series SPST-NO 16 A 3 V 2 Coil Latching PC Pin Through Hole Power Relay
Technical Details
| Coil Current | 133.3mA |
| Coil Power | 400mW |
| Coil Resistance | 22.5Ω |
| Coil Type | Latching, Dual Coil |
| Coil Voltage (DC) | 2.4V |
| Contact Current Rating | 16A |
| Contact Material | Silver, Tin |
| Contact Resistance | 100mΩ |
| Contact Voltage Rating (AC) | 277V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 50kcycles |
| Height | 18.8mm |
| Insulation Resistance | 1GΩ |
| Introduction Date | 2013-11-20 |
| Lead Free | Lead Free |
| Length | 24mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -40°C |
| Number of Pins | 5 |
| Number of Terminals | 5 |
| Operate Time | 15ms |
| Power Rating | 400mW |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 15ms |
| Response Time | 15ms |
| RoHS | Compliant |
| Termination | PC Pin |
| Throw Configuration | SPST |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
