ADW1224HT - Panasonic
Power/Signal Relay, 1 Form A, SPST, Momentary, 26.4VDC (Coil), DC Input, Random, AC Output
Technical Details
| Coil Resistance | 1.44kΩ |
| Coil Voltage (DC) | 19.2V |
| Contact Current Rating | 16A |
| Contact Resistance | 100mΩ |
| Contact Voltage Rating (AC) | 277V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 50kcycles |
| Height | 18.8mm |
| Insulation Resistance | 1GΩ |
| Introduction Date | 2013-11-20 |
| Lead Free | Lead Free |
| Length | 24mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -40°C |
| Number of Pins | 5 |
| Number of Terminals | 5 |
| Power Rating | 400mW |
| Release Time | 15ms |
| Response Time | 15ms |
| RoHS | Compliant |
| Schedule B | 8536490075 |
| Throw Configuration | SPST |
Compliance
RoHS : Unconfirmed
Images
Newark
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Panasonic | Production |
