Technical Details
| Coil Current | 59mA |
| Coil Power | 1.4W |
| Coil Resistance | 410Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 24V |
| Contact Current Rating | 33A |
| Contact Material | Silver, Tin |
| Contact Resistance | 100Ω |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 23.3mm |
| Introduction Date | 2023-08-30 |
| Lead Free | Lead Free |
| Length | 31.1mm |
| Lifecycle Status | Production |
| Max Current Rating | 33A |
| Max Operating Temperature | 60°C |
| Max Voltage Rating (AC) | 250V |
| Min Operating Temperature | -40°C |
| Number of Pins | 4 |
| Operate Time | 20ms |
| Power Consumption | 1.4W |
| Power Rating | 1.4W |
| Relay Type | General Purpose |
| Release Time | 10ms |
| RoHS | Compliant |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Weight | 23g |
| Width | 15.7mm |
Compliance
RoHS : Unconfirmed
