ALZ12B5T - Panasonic
Relay, 1 Form C (no/nc), 5 V (DC), 63 Ω, 16 A, 440 V (AC), Monostable, ALZ12B5T
Technical Details
| Case/Package | DIP |
| Coil Current | 80mA |
| Coil Resistance | 63Ω |
| Coil Voltage (DC) | 5V |
| Contact Current Rating | 16A |
| Contact Material | Silver, Tin |
| Depth | 12.5mm |
| Lead Free | Lead Free |
| Length | 28.8mm |
| Max Current Rating | 16A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 440V |
| Min Operating Temperature | -40°C |
| Number of Pins | 8 |
| Operate Time | 15ms |
| Power Rating | 400mW |
| RoHS | Compliant |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 440V |
Compliance
RoHS : Unconfirmed
