APAN3124 - Panasonic
Power Relay, Spst-no, 24 VDC, Slim Design, High Insulation, Pa-n Series
Technical Details
| Ambient Temperature Range High | 90°C |
| Coil Current | 5mA |
| Coil Power | 110mW |
| Coil Resistance | 5.236kΩ |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 16.8V |
| Contact Current Rating | 5A |
| Contact Material | Gold, Silver |
| Contact Resistance | 30mΩ |
| Contact Voltage Rating (AC) | 250V |
| Current Rating | 5A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 50kcycles |
| Height | 12.5mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.49.00.50 |
| Introduction Date | 2016-04-27 |
| Lead Free | Lead Free |
| Length | 20mm |
| Lifecycle Status | Production |
| Max Current Rating | 5A |
| Max Operating Temperature | 90°C |
| Max Voltage Rating (DC) | 110V |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 1 |
| Operate Time | 10ms |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 5ms |
| Response Time | 10ms |
| RoHS | Compliant |
| Sealable | MOISTURE PROOF, RT3 |
| Switching Current | 5A |
| Termination | PC Pin |
| Throw Configuration | SPST |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
