AQW223R2S - Panasonic
AQW Photomos Series 0.14 A 250 V 15 Ohm 2 Channel Solid State Relay - SOIC-8
Technical Details
| Ambient Temperature Range High | 85°C |
| Capacitance | 33pF |
| Case/Package | SOP |
| Contact Resistance | 11Ω |
| Forward Current | 50mA |
| Height | 2.3mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.95.00 |
| Input Current | 30mA |
| Introduction Date | 2006-12-22 |
| Isolation Voltage | 1500Vrms |
| Lead Free | Lead Free |
| Length | 9.37mm |
| Lifecycle Status | Production |
| Load Current | 140mA |
| Max Input Current | 50mA |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 85°C |
| Max Output Current | 140mA |
| Max Output Voltage | 250V |
| Max Power Dissipation | 650mW |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Contacts | 2 |
| Number of Elements | 2 |
| Number of Pins | 8 |
| On-State Resistance | 15Ω |
| Output Current | 140mA |
| Output Voltage | 125V |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | Relay |
| RoHS | Compliant |
| Schedule B | 8536410030, 8536410030|8536410030, 8536410030|8536410030|8536410030, 8536410030|8536410030|8536410030|8536410030 |
| Termination | Gull Wing |
| Throw Configuration | DPST |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
