AQY221N2M1Y - Panasonic
AQY Photomos Series 120 mA 40 V 12.5 Ohm SMT 1 Channel Solid State Relay - SON-4
Technical Details
| Ambient Temperature Range High | 85°C |
| Capacitance | 1.1pF |
| Case/Package | SMD/SMT |
| Data Polarity | DC |
| Forward Current | 3mA |
| Height | 1.4mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.95.00 |
| Input Current | 1mA |
| Introduction Date | 2022-04-22 |
| Isolation Voltage | 200Vrms |
| Lead Free | Lead Free |
| Length | 2.95mm |
| Lifecycle Status | Production |
| Load Current | 120mA |
| Max Length | 2.95mm |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 300mW |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Contacts | 1 |
| Number of Elements | 1 |
| Number of Pins | 4 |
| On-State Resistance | 12.5Ω |
| Output Current | 120mA |
| Output Voltage | 15V |
| Packaging | Tape & Reel (TR) |
| Relay Type | Relay |
| Resistance | 12.5Ω |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Throw Configuration | SPST |
| Width | 2.2mm |
Compliance
RoHS : Unconfirmed
