Technical Details
| Ambient Temperature Range High | 105°C |
| Capacitance | 14.5pF |
| Case/Package | SMD/SMT |
| Data Polarity | AC/DC |
| Forward Current | 200µA |
| Height | 800µm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.95.00 |
| Input Current | 40µA |
| Introduction Date | 2017-03-23 |
| Isolation Voltage | 200Vrms |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Load Current | 300mA |
| Max Length | 1.95mm |
| Max Operating Temperature | 105°C |
| Max Power Dissipation | 250mW |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Contacts | 1 |
| Number of Elements | 1 |
| Number of Pins | 4 |
| On-State Resistance | 1.5Ω |
| Output Current | 300mA |
| Output Voltage | 15V |
| Packaging | Tape & Reel (TR) |
| REACH SVHC | Yes |
| Relay Type | Relay |
| Resistance | 1.5Ω |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Throw Configuration | SPST |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
