DE1AL23D - Panasonic
Relay, 1 Form A (n/o), 3 V (DC), 45 Ω, 10 A, 30 V (DC), 250 V (AC), Monostable, DE1AL23D
Technical Details
| Coil Resistance | 45Ω |
| Contact Material | Silver, Tin |
| Contact Resistance | 30Ω |
| Lead Free | Lead Free |
| Length | 25mm |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -40°C |
| Number of Pins | 8 |
| Operate Time | 10ms |
| Power Rating | 200mW |
| Ratings | IP67 |
| RoHS | Compliant |
| Switching Capacity | 2.5kW |
| Switching Current | 10A |
| Throw Configuration | SPST |
Compliance
RoHS : Unconfirmed
