Technical Details
| Coil Current | 30mA |
| Coil Power | 150mW |
| Coil Resistance | 167Ω |
| Coil Voltage (DC) | 4V |
| Contact Current Rating | 5A |
| Contact Plating | Gold |
| Contact Resistance | 30mΩ |
| Contact Voltage Rating (AC) | 250V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 100kcycles |
| Height | 10.5mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.49.00.50 |
| Insulation Resistance | 1GΩ |
| Introduction Date | 2013-04-19 |
| Lead Free | Lead Free |
| Length | 20.2mm |
| Lifecycle Status | Production |
| Max Current Rating | 5A |
| Max Operating Temperature | 60°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 125V |
| Min Operating Temperature | -40°C |
| Number of Pins | 6 |
| Number of Terminals | 6 |
| Packaging | Box |
| Power Rating | 150mW |
| REACH SVHC | Yes |
| Release Time | 5ms |
| Response Time | 10ms |
| RoHS | Compliant |
| Throw Configuration | DPST |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
