TQ2SA-L-5V - Panasonic
Relay, Surface Mount; 14 mA 10 % (Operational) (Typ.); 5 VDC (Typ.); DPDT
Technical Details
| Ambient Temperature Range High | 85°C |
| Approvals | CSA, UL |
| Coil Current | 14mA |
| Coil Power | 70mW |
| Coil Resistance | 357Ω |
| Coil Type | Latching, Single Coil |
| Coil Voltage (DC) | 3.75V |
| Contact Current Rating | 2A |
| Contact Material | Silver |
| Contact Plating | Gold |
| Contact Resistance | 75mΩ |
| Contact Voltage Rating (AC) | 125V |
| Current Rating | 2A |
| Depth | 11.5mm |
| Electrical Life | 100kcycles |
| Height | 5.4mm |
| Insertion Loss (dB) | 0.8dB |
| Insulation Resistance | 1GΩ |
| Lead Free | Lead Free |
| Length | 14mm |
| Lifecycle Status | Production |
| Max Current Rating | 2A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (AC) | 125V |
| Max Voltage Rating (DC) | 220V |
| Min Operating Temperature | -40°C |
| Mount | PCB, Surface Mount |
| Number of Contacts | 2 |
| Number of Pins | 8 |
| Number of Terminals | 10 |
| Operate Time | 4ms |
| Power Consumption | 70mW |
| REACH SVHC | Yes |
| Relay Type | Telecom |
| Release Time | 4ms |
| Resistance | 357Ω |
| Response Time | 4ms |
| RoHS | Compliant |
| Switching Current | 2A |
| Termination | Gull Wing |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 125V |
| Weight | 2g |
| Width | 14mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
