1461034-2 - TE Connectivity / AMP
AgCdO 5V 8A Normal Open: 1A(SPST-Normal Open) Plugin, 10.2x18.2mm Power Relays ROHS
Technical Details
| Ambient Temperature Range High | 105°C |
| China RoHS | Non-Compliant |
| Coil Current | 40mA |
| Coil Power | 200mW |
| Coil Resistance | 125Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 3.75V |
| Contact Current Rating | 8A |
| Contact Material | Cadmium, Silver |
| Contact Voltage Rating (AC) | 277V |
| Contact Voltage Rating (DC) | 30V |
| Current Rating | 8A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 100kcycles |
| ELV | Non-Compliant |
| Height | 14.7mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.20 |
| Introduction Date | 2008-03-19 |
| Length | 18.2mm |
| Lifecycle Status | Production |
| Max Current Rating | 8A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 30V |
| Min Operating Temperature | -40°C |
| Number of Contacts | 1 |
| Number of Pins | 1 |
| Power Consumption | 200mW |
| REACH SVHC | No |
| Release Time | 4ms |
| Response Time | 15ms |
| RoHS | Compliant |
| Termination | PCB |
| Throw Configuration | SPST |
| Weight | 9g |
| Width | 10.16mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
