1-1393224-4 - TE Connectivity
Power Relay 5VDC 8A SPST-NO (( 28.5mm 10.1mm 12.3mm)) Through Hole
Technical Details
| Ambient Temperature Range High | 70°C |
| China RoHS | Compliant |
| Coil Current | 44mA |
| Coil Power | 220mW |
| Coil Resistance | 112Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 3.5V |
| Contact Current Rating | 8A |
| Contact Material | Gold, Silver |
| Contact Plating | Gold |
| Contact Voltage Rating (AC) | 250V |
| Current Rating | 8A |
| Depth | 10.1mm |
| Dropout Voltage | 500mV |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 30kcycles |
| ELV | Compliant |
| Height | 12.3mm |
| Introduction Date | 2005-06-08 |
| Lead Free | Lead Free |
| Length | 28.5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 8A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (AC) | 400V |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 4 |
| Operate Time | 9ms |
| Packaging | Box |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Release Time | 4ms |
| Response Time | 8ms |
| RoHS | Compliant |
| Sealable | RT3 |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 400V |
| Weight | 8g |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
