1-1415898-6 - TE Connectivity
Power Relay, Spst-No, 16A, 250V, Socket Rohs Compliant: Yes |Schrack Te Connectivity RTS3T005
Technical Details
| Ambient Temperature Range High | 105°C |
| Case/Package | DIP |
| China RoHS | Compliant |
| Coil Current | 81mA |
| Coil Power | 403mW |
| Coil Resistance | 62Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 3.5V |
| Contact Current Rating | 16A |
| Contact Material | Silver, Tin |
| Contact Voltage Rating (AC) | 400V |
| Current Rating | 16A |
| Depth | 12.7mm |
| Dropout Voltage | 500mV |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ELV | Compliant |
| Height | 15.7mm |
| Introduction Date | 2008-04-02 |
| Lead Free | Lead Free |
| Length | 29mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 16A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 400V |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 6 |
| Number of Terminals | 7 |
| Operate Time | 10ms |
| Packaging | Carton |
| Power Consumption | 400mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 9ms |
| Response Time | 14ms |
| RoHS | Compliant |
| Sealable | RT2 |
| Termination | Plug |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 400V |
| Weight | 14g |
| Width | 12.7mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
