1-1415899-1 - TE Connectivity
Electromechanical Relay 24VDC 1.44KOhm 12A SPDT (29x12.7x15.7)mm THT Power Relay
Technical Details
| Ambient Temperature Range High | 85°C |
| Approvals | UL, VDE |
| China RoHS | Compliant |
| Coil Current | 17mA |
| Coil Power | 400mW |
| Coil Resistance | 1.44kΩ |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 16.8V |
| Contact Current Rating | 12A |
| Contact Material | Silver, Tin |
| Contact Voltage Rating (AC) | 400V |
| Current Rating | 12A |
| Depth | 12.7mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 30kcycles |
| ELV | Compliant |
| Height | 15.7mm |
| Introduction Date | 2010-05-26 |
| Lead Free | Lead Free |
| Length | 29mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 12A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 400V |
| Min Operating Temperature | -40°C |
| Mount | PCB, Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 5 |
| Operate Time | 8ms |
| Packaging | Carton |
| Power Rating | 400mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 12ms |
| Response Time | 14ms |
| RoHS | Compliant |
| Schedule B | 8536490075|8536490075 |
| Sealable | RT2 |
| Termination | PC Pin, PCB |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 400V |
| Voltage Rating (DC) | 24V |
| Weight | 10g |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
