1393280-6 - TE Connectivity
Electromechanical Relay 12VDC 254Ohm 40A SPDT (12.9x12x9.9)mm THT Power Relay
Technical Details
| Ambient Temperature Range High | 105°C |
| China RoHS | Compliant |
| Coil Current | 47mA |
| Coil Power | 567mW |
| Coil Resistance | 254Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 6.9V |
| Contact Current Rating | 1.33A |
| Contact Material | Silver, Tin |
| Contact Voltage Rating (AC) | 12V |
| Current Rating | 30A |
| Depth | 12mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 100kcycles |
| ELV | Compliant |
| Height | 9.9mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.05 |
| Introduction Date | 2005-02-02 |
| Lead Free | Lead Free |
| Length | 11.9888mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 1.33A |
| Max Operating Temperature | 105°C |
| Max Voltage Rating (DC) | 12V |
| Min Operating Temperature | -40°C |
| Mount | PCB, Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 5 |
| Operate Time | 3ms |
| Packaging | Box |
| Power Consumption | 550mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | Relay |
| Release Time | 1.5ms |
| Response Time | 3ms |
| RoHS | Compliant |
| Sealable | IP67, RT3 |
| Termination | PCB, Through Hole |
| Throw Configuration | SPDT |
| Voltage Rating (DC) | 12V |
| Weight | 4g |
| Width | 12.9mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
