1415898-6 - TE Connectivity
Relay, 1 Form A (n/o), 24 V (DC), 886 Ω, 16 A, 400 V (AC), Bistable, 1415898-6
Technical Details
| Ambient Temperature Range High | 105°C |
| China RoHS | Compliant |
| Coil Current | 27mA |
| Coil Power | 650mW |
| Coil Resistance | 886Ω |
| Coil Type | Latching, Dual Coil |
| Coil Voltage (DC) | 16.8V |
| Contact Current Rating | 16A |
| Contact Material | Silver, Tin |
| Contact Voltage Rating (AC) | 400V |
| Current Rating | 16A |
| Depth | 12.7mm |
| Dropout Voltage | 16.8V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ELV | Compliant |
| Height | 15.7mm |
| Introduction Date | 2008-04-02 |
| Lead Free | Lead Free |
| Length | 29mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 16A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 400V |
| Min Operating Temperature | -40°C |
| Mount | PCB, Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 7 |
| Number of Terminals | 7 |
| Operate Time | 10ms |
| Power Consumption | 650mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Release Time | 14ms |
| Response Time | 14ms |
| RoHS | Compliant |
| Schedule B | 8536490080|8536490080|8536490080|8536490080|8536490080 |
| Sealable | RT2 |
| Termination | Plug, Through Hole |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 400V |
| Weight | 14g |
| Width | 12.7mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
