1461352-2 - TE Connectivity
Electromechanical Relay 5VDC 125Ohm 10A SPST-NO (( 20mm 10mm 15.2mm)) THT Miniature PCB Relay
Technical Details
| Ambient Temperature Range High | 85°C |
| China RoHS | Compliant |
| Coil Current | 40mA |
| Coil Power | 200mW |
| Coil Resistance | 125Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 3.75V |
| Contact Current Rating | 5A |
| Contact Material | Silver, Tin |
| Contact Voltage Rating (AC) | 277V |
| Current Rating | 5A |
| Depth | 10mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 30kcycles |
| ELV | Compliant |
| Height | 15.2mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.20 |
| Introduction Date | 2006-08-22 |
| Length | 19.8mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 5A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (AC) | 277V |
| Max Voltage Rating (DC) | 30V |
| Min Operating Temperature | -40°C |
| Mount | PCB, Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 4 |
| Number of Terminals | 4 |
| Operate Time | 10ms |
| Packaging | Bulk |
| Power Consumption | 200mW |
| REACH SVHC | Yes |
| Release Time | 5ms |
| Response Time | 10ms |
| RoHS | Compliant |
| Sealable | RT2 |
| Termination | PCB, Through Hole |
| Throw Configuration | SPST |
| Weight | 7g |
| Width | 10mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
