1558665-3 - TE Connectivity
Power Relay 12VDC Control 160 Ohm SPDT 20A/250VAC Through Hole T9G Series
Technical Details
| Ambient Temperature Range High | 105°C |
| China RoHS | Compliant |
| Coil Power | 900mW |
| Coil Resistance | 160Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 12V |
| Contact Current Rating | 20A |
| Contact Voltage Rating (AC) | 480V |
| Current Rating | 20A |
| Height | 15.7mm |
| Length | 29mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 20A |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Number of Contacts | 1 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Switching Current | 20A |
| Throw Configuration | SPDT |
| Weight | 18g |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
