1649399-4 - TE Connectivity
Relay, 1 Form C (no/nc), 12 V (DC), 270 Ω, 16 A, 24 V (DC), 240 V (AC), Monostable, 1649399-4
Technical Details
| Ambient Temperature Range High | 70°C |
| China RoHS | Compliant |
| Coil Current | 45mA |
| Coil Power | 540mW |
| Coil Resistance | 270Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 9V |
| Contact Current Rating | 16A |
| Contact Material | Silver, Tin |
| Contact Voltage Rating (AC) | 240V |
| Current Rating | 16A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 100kcycles |
| ELV | Compliant |
| Height | 20.6mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.50 |
| Insulation Resistance | 1GΩ |
| Introduction Date | 2010-09-24 |
| Length | 29.2mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 16A |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 24V |
| Min Operating Temperature | -30°C |
| Mount | Through Hole |
| Number of Contacts | 1 |
| Operate Time | 20ms |
| Packaging | Box |
| REACH SVHC | Yes |
| Release Time | 8ms |
| Response Time | 20ms |
| RoHS | Compliant |
| Sealable | RT2 |
| Termination | PCB |
| Throw Configuration | SPDT |
| Weight | 13g |
| Width | 12.8mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
