2-1393302-2 - TE Connectivity
Power Relay 12VDC 120(NO)/45(NC)A SPDT(25.9x29.9x51.9)mm Plug-In Automotive
Technical Details
| Ambient Temperature Range High | 125°C |
| China RoHS | Compliant |
| Coil Current | 132mA |
| Coil Power | 1.58W |
| Coil Resistance | 90Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 7.2V |
| Contact Current Rating | 750mA |
| Contact Material | Silver |
| Contact Voltage Rating (AC) | 12V |
| Depth | 26.2mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 200kcycles |
| ELV | Compliant |
| Flammability Rating | UL94 HB |
| Height | 24.9mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.05 |
| Introduction Date | 2005-02-02 |
| Lead Free | Not Applicable |
| Length | 25.908mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 750mA |
| Max Operating Temperature | 125°C |
| Max Voltage Rating (DC) | 12V |
| Min Operating Temperature | -40°C |
| Mount | Plug-In |
| Number of Contacts | 1 |
| Number of Pins | 5 |
| Operate Time | 7ms |
| Packaging | Bulk |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | Relay |
| Release Time | 2ms |
| Response Time | 7ms |
| RoHS | Compliant |
| Sealable | DUST PROOF |
| Termination | Plug, Quick Connect |
| Throw Configuration | SPDT |
| Weight | 35g |
| Width | 25.908mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
