2-1419142-2 - TE Connectivity
Electromechanical Relay 3VDC 45Ohm 5A SPDT(20x10x10)mm THT Industrial Relay
Technical Details
| Ambient Temperature Range High | 85°C |
| China RoHS | Compliant |
| Coil Current | 66.7mA |
| Coil Power | 200mW |
| Coil Resistance | 45Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 3V |
| Contact Current Rating | 5A |
| Contact Material | Silver |
| Contact Voltage Rating (AC) | 400V |
| Current Rating | 5A |
| Depth | 10mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ELV | Compliant |
| Height | 10mm |
| Insulation Resistance | 10TΩ |
| Introduction Date | 2014-01-20 |
| Length | 20mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 5A |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Number of Contacts | 1 |
| Number of Pins | 1 |
| Packaging | Carton |
| REACH SVHC | Yes |
| Resistance | 45Ω |
| RoHS | Compliant |
| Termination | PCB |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 400V |
| Weight | 5g |
| Width | 10mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
