3-1393240-0 - TE Connectivity
1 Form A SPST-NO, 16 A Contact Rating 5 VDC General Purpose Power Relay RT33L005
Technical Details
| Ambient Temperature Range High | 85°C |
| China RoHS | Compliant |
| Coil Current | 80.65mA |
| Coil Power | 403mW |
| Coil Resistance | 62Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 5V |
| Contact Current Rating | 16A |
| Contact Material | Silver, Tin |
| Contact Voltage Rating (AC) | 400V |
| Current Rating | 16A |
| Depth | 12.7mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ELV | Compliant |
| Height | 15.7mm |
| Introduction Date | 2009-09-11 |
| Lead Free | Lead Free |
| Length | 29mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 16A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 400V |
| Min Operating Temperature | -40°C |
| Mount | Socket, Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 7 |
| Number of Terminals | 6 |
| Operate Time | 9ms |
| Packaging | Carton |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Release Time | 3ms |
| Response Time | 8ms |
| RoHS | Compliant |
| Termination | Plug |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 400V |
| Weight | 14g |
| Width | 12.7mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
