3-1419153-5 - TE Connectivity
Electromechanical Relay SPST-NO 25A 12VDC 160Ohm Through Hole
Technical Details
| Ambient Temperature Range High | 75°C |
| China RoHS | Compliant |
| Coil Current | 75mA |
| Coil Power | 900mW |
| Coil Resistance | 160Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 12V |
| Contact Current Rating | 25A |
| Contact Material | Silver, Tin |
| Contact Voltage Rating (AC) | 277V |
| Current Rating | 26A |
| Depth | 16mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ELV | Compliant |
| Height | 26.5mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.50 |
| Insulation Resistance | 1GΩ |
| Introduction Date | 2008-04-04 |
| Length | 30.4mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 25A |
| Max Operating Temperature | 55°C |
| Max Voltage Rating (DC) | 24V |
| Min Operating Temperature | -30°C |
| Mount | Through Hole |
| Number of Contacts | 1 |
| Number of Terminals | 4 |
| Packaging | Bulk |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Width | 16mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
