3-2158000-5 - TE Connectivity
TE Connectivity 3-2158000-5 RZ01-1A4-D005-R Relay SPST 5VDC 10A PCB Terminal
Technical Details
| Ambient Temperature Range High | 85°C |
| China RoHS | Compliant |
| Coil Power | 420mW |
| Coil Resistance | 60Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 5V |
| Contact Current Rating | 12A |
| Contact Voltage Rating (AC) | 400V |
| Current Rating | 12A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 15.7mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.49.00.75 |
| Introduction Date | 2019-09-21 |
| Length | 29mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 12A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 300V |
| Number of Contacts | 1 |
| Number of Pins | 1 |
| Packaging | Carton |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | PCB |
| Width | 12.7mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
