4-1440000-2 - TE Connectivity
Electromechanical Relay 24VDC 820Ohm 10A SPDT (29.2x12.8x20.6)mm THT Power Relay
Technical Details
| Ambient Temperature Range High | 85°C |
| China RoHS | Non-Compliant |
| Coil Current | 30mA |
| Coil Power | 720mW |
| Coil Resistance | 820Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 16.8V |
| Contact Current Rating | 10A |
| Contact Material | Cadmium, Silver, Tin |
| Contact Voltage Rating (AC) | 250V |
| Current Rating | 16A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 100kcycles |
| ELV | Non-Compliant |
| Height | 20.6mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.41.00.20 |
| Introduction Date | 2003-06-02 |
| Lead Free | Lead Free |
| Length | 29.2mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 10A |
| Max Operating Temperature | 55°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 30V |
| Min Operating Temperature | -30°C |
| Mount | PCB, Through Hole |
| Number of Contacts | 1 |
| Number of Pins | 5 |
| Operate Time | 15ms |
| Power Consumption | 720mW |
| REACH SVHC | Yes |
| Relay Type | General Purpose |
| Release Time | 8ms |
| Response Time | 15ms |
| RoHS | Compliant |
| Sealable | PLASTIC SEALED |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| Width | 12.8mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
