7-1393239-7 - TE Connectivity
General Purpose Power PCB Electromechanical Relay SPDT 16A 3VDC 21Ohm Through Hole
Technical Details
| Ambient Temperature Range High | 85°C |
| China RoHS | Compliant |
| Coil Current | 143mA |
| Coil Power | 429mW |
| Coil Resistance | 21Ω |
| Coil Voltage (DC) | 2.1V |
| Contact Current Rating | 16A |
| Contact Voltage Rating (AC) | 400V |
| Current Rating | 16A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ELV | Compliant |
| Height | 15.7mm |
| Introduction Date | 2011-09-01 |
| Length | 29mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Current Rating | 16A |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Socket |
| Number of Contacts | 1 |
| Number of Terminals | 9 |
| Packaging | Carton |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Release Time | 10ms |
| Response Time | 10ms |
| RoHS | Compliant |
| Sealable | RT2 |
| Termination | Plug |
| Throw Configuration | SPDT |
| Weight | 14g |
| Width | 12.7mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
